VERSION | R185EHP15

Hourly capacity

6 - 7

m³/h*

Throat opening

160 x 90 (RI) 160 x 150

mm

90

Ø max.* mm

2

Blades

10

Hammers

1

Counter-blade

Image R185EHP15
R185EHP15
Image R185EHP15
R185EHP15

Basic equipment

DISC | Blades+Counter-blade

Sharpenable blades (hardened steel)

Mobile reversible hammers (hardened steel)

Adjustable counter-blade

Mobile refining screen

Rotary ejection pipe with adjustable discharge distance

Lubrication system for bearings

Hopper with handle for displacement of the machine

Belt transmission

2 pneumatic wheels

380 V - 50 Hz

Ejection pipe extension (400 mm)

Cutting system
Blades (hardened steel) N° 2
Hammers (hardened steel) N° 10
Counter-blade N° 1
Features
Hourly capacity m³/h* 6 - 7
Throat opening mm 160 x 150
To shred - Ø max.* mm 90
Motive power
Power hp/kW 15 / 11
Power source Electric
Engine/motor 380 V - 50 Hz
Fuel consumption liters/h /
Specifications
Length mm 1785
Width mm 860
Height mm 1765
Discharge height mm 1765
Introduction height mm 1135
Hopper size mm 600 x 585
Weight: NET kg 190
* Input material - Data depending on the kind of material and working conditions.
TERMS
Product origin Made in Italy
Warranty 2 years for EU countries / 1 year for non-EU countries - from invoice date
Delivery - Original spare parts Usually available, 45 days max. (from order date)
Identification - SCIP number (link) https://echa.europa.eu/it/scip-database
Instructions -SIP number (PDF)
The products are subject to technical evolution and this website may not be fully updated.
The data in the tables, the photos and pictures have to be considered informative and not binding.
